ProFX6v3 Dimensions
ProFX10v3 Dimensions
WEIGHT
2.6 lb
1.2 kg
7.5 in / 191 mm
2.9 in
74 mm
8.4 in
213 mm
WEIGHT
4.9 lb
2.2 kg
10.7 in / 272 mm
3.3 in
84 mm
11.9 in
302 mm
