Page 10 of 20
General
Connector M12 (DIN)
Standards / regulations IEC 61076-2-101
Part Number MXD-C1.5S
Description 1.5 meter connection cable (straight plug/socket)
Number of positions 5
Protection IP67
Material of body TPU (thermoplastic polyurethane)
Knurled section zinc die-cast, nickel-plated
Rated voltage / current 60v / 4A
Contact resistance Max 5 mΩ
Ambient temperature (plug and socket) -25°C - 90°C
Core Number 5 core
Core colours brown, white, blue, black, green-yellow
Cable material PUR (polyurethane)
External diameter 5mm
Conductor cross section
5 x 0.34mm² (signal lines)
Rated voltage / current 60v / 4A
Ambient Temperature (operation) -25°C - 90°C (cable, fixed installation)
Cable resistant to acids, alkaline solutions and salt water
