Motor Mount Assembly:
• Motor/gearbox, Hybrid Hub, and keyless bushing adapter attached to motor mount.
• If ordered without safety screens, the Hybrid hub cover, hub safety system, and blade
struts will also be attached to the hub.
Wall Mount Assembly:
• V-shaped wall mount.
• Pivot mount (attached to wall mount).
If the fan is ordered with screens, the following will be in the box:
• Safety cable.
• Safety cable bolt kit.
• Blade bolt kit.
• Keyless bushing adapter.
• Bolts and washers to attach keyless bushing adapter to hub.
• Packet of bolts, nuts, and washers to attach rear screen to motor mount.
• Packet of large sheet metal screws to attach front screen to rear screen.
• Hub cover.
• Screws and star washers to attach hub cover.
• Solid Steel Blade Struts.
• Solid Steel Blade Struts to Hybrid Hub bolt pack.
If the fan is ordered without screens, the following will be in the box.
• Safety cable.
• Safety cable bolt kit.
• Blade bolt kit.
• Blade safety links and safety link extenders.
Note: All of the components listed to the left are in the power unit crate. If the fan is
ordered with screens, they will be on a separate pallet. Blades will be on a separate
pallet.
