Macrom M-DL7000D User Manual

- 23 -
Wire Connections
Red
White
Yellow
Red
White
Red
White
Brown Brown
USB-0.5A
Pink
Green with White
Black
Orange with white
Brown with white Blue
MIC
LINE OUTPUT
& AV IN
USB
MICROPHONE
SWC &
CAMERA IN
RADIO FM/AM Antenna
DAB Antenna
SUB 1
SUB 2
Front L
Front R
Rear L
Rear R
Video
Aux L
Aux R
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right / Gray
Front right (-) / Gray with black stripe
Front left (+) / White
Front left (-) / White with black stripe
ACC+ / Red
Rear left (+) / Green
Ground / Black
Battery 12V(+) / Yellow
Rear left (-) / Green with black stripe
Function
Connector A Connector B
PIN NO.
Illumination / Orange
Antenna-Power Control/ Blue
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Camera IN
Video Out
PARKING
REVERSE SWC GND
SWC2
SWC1
P.CONT
Video Out
Yellow
CONNECTOR A
CONNECTOR B
CONNECTOR A
CONNECTOR B
Yellow
Not available
