Features
RMS Power at 4 ohm Stereo load at 14,4 volts 300 x 1 watts
RMS Power at 2 ohm Stereo load at 14,4 volts 500 x 1 watts
THD (total Harmonic Distortion) < 0,1%
Frequency response (+0/-1 dB) 10 - 300Hz
Signal to noise ratio > 95dB
Low Input sensitivity 200-8,000mV
High Input sensitivity 1/10V
Input impedance 22k/100ohm
Crossover type Variable 24dB/octave
Crossover frequency (Low-pass) 30 to 600Hz
Sub sonic filter 20 to 50HZ at 24dB/octave
Bass Boost 0 to 12dB @ 40Hz
Line Out 1-1 (by pass)
EBC “Expernal Bass Control” YES
Dimension (w * h * d) mm 244 x 54 x 280
06
• Class D mono channel power amplifier
• 500 watts into 2 ohms load
• 300 watts into 4 ohms load
• P-Mosfet on amplifier stage
• Variable Low pass x-over at 24dB/oct
• Variable Sub sonic filter from 20 to 50Hz at 24dB/oct
• Adjustable Bass Boost from 0 to +12dB at 45Hz
• EBC external bass control
• Pre-amplified Line output
• High level Input (booster In)
• Mos-Fet power supply
• Screws terminals connectors
Technical data
