10
TECHNICAL DATA
Power IHF 202 650W
RMS Power at (12.5 Volts DC)
Front/Rear at 1 kHz < 0.08 % THD+N at 4 Ohm 4 x 75 W
Front/Rear at 1 kHz < 0.5 % THD+N at 2 Ohm 4 x 150 W
Front/Rear at 1 kHz < 0.5 % THD+N Mono at 4 Ohm 2 x 300 W
Pre-Out Sensitivity 1:1
High pass, Front and Rear (30-600)Hz
Low pass, Front and Rear (30-600)Hz
Crossover slope 12 dB/Octave
Response in frequency +/- 1 dB 10 - 50.000 Hz
Total harmonic distortion 0.08%
Weighted IHF A Signal-Noise Ratio > 100 dB
Input sensitivity - Impedance 200-4000 mV/22 kOhm
Loudspeaker impedances
Stereo min. 2 Ohms
Mono min. 4 Ohms
Power supply 14.4 V DC
(11 - 16 V permissible)
Weight 5,1 kgrs
Dimensions 212(I) x 67(H) x 445(D) mm
Due to the continual incorporation of improvements in this product, the characteristics and
design may be subject to variation without prior notice.
O/M ST 4.075 25/06/02 18:35 Page 10
