Madimack ECO - Protection & Failure Codes

45
Protection & Failure Code
Error
Component corresponding
What did the error detect?
Solution
E1
High pressure protection
High gas pressure switch
1. Check the water flow from the filtration pump and
ventilation clearances. 2. Check high pressure switch is
closed circuit 3. Replace PCB 4. replace inverter board
E2
Low pressure protection
Low gas pressure switch
1. Check the water flow from the filtration pump and
ventilation clearances. 2. Check low pressure switch is
open circuit 3. Replace PCB 4. replace inverter board
E3
No water protection
Low water flowrate
Check the water flow in pipes, and filtration pump is
running. Check filters, skimmer basket, back wash
Check the bypass or valves have not been adjusted since
commissioned
Check the Water flow switch
E4
3 phases sequence protection
Electrical power connection
Check the power connection to the pump
E5
Power supply excesses operation
range (Not failure)
1). Recover when back to the normal power
2). Replace PCB
E6
Excessive temp difference between
inlet and outlet water (Insufficient
waterflow protection)
High temperature difference
Check the water flow in pipes, and filtration pump is
running.
Check the bypass is opened and unit is commissioned
Check the Water flow switch
E7
Water outlet temp too high or too
low protection
Water flowrate in pipes
Check if there is any blockage in the inlets, outlets, and
through the pipe
E8
High exhaust temp protection
Compressor overheating
Check if refrigerant gas is leaking, check the connection
of the sensor, might need to change if faulty, check the
compressor of the pump
Eb
Ambient temperature too high or
too low protection (not failure)
Out of the heat pump’s
capacity to withdraw heat from
the atmosphere
Out of application range
Ed
Anti-freezing reminder (not failure)
Wait for automatic recovery
F1
Compressor drive module failure
Lack of phase
Check the voltage and the frequency conversion
F2
PFC module failure
PFC circuit
Check the PFC switch circuit if short or not
F3
Compressor start failure
Compressor circuit
Check the compressor wiring if its correct or if there is
any short circuit
F4
Compressor running failure
Compressor circuit
Check the compressor wiring if its correct or if there is
any short circuit
F5
Inverter board over current
protection
1). Wiring
2). Inverter board
3). PCB
F6
Inverter board overheat protection
Inverter board high temp
Check the current flowing it might need to
F7
Current protection
1). Power off and restart
2). Inverter board
3). Compressor
F8
Cooling plate overheat protection
1). Power off and restart
2). Check fan motor
3). Check cooling plate
F9
Fan motor failure
Fan motor
Check the fan motor wiring, check if the fan is broken or
loose
Fb
Power filter plate No-power
protection
Power filter not working
Single Phase Model
1). Replace Inverter board
3 Phases Model
1). Replace power filter plate
FA
PFC module over current
protection
Solar inverter voltage change
Power black out
1). Initial power testing has completed.
Power off and restart (happens install with solar PV)
