C. Installation guidance
1. Installation reminder
Only competent persons are authorized to install the heat pump and should be educated with the relevant
building codes and standards of their current state or local governing body for all electrical, mechanical
and water services to prevent danger or damage to the unit.
a. Location and water pipe connection
The inverter pool heat pump must be installed in a well-ventilated place.
b. Typical installation diagram
Installations can differ dependent on site conditions below is only a representation of one possibility.
Note: the inlet and outlet positions for the pipework is a representation only and can be positioned
differently
