MAG Z Series User Manual

11
info@mag-audio.com Tel./Fax: +38 044 277-47-89 www.mag-audio.com
Z Series User Manual rev 2.10
System Z 320A Z 350A Z 355A Z 318A
Type
Powered full-range
speaker
Powered full-range
speaker
Powered full-range
speaker
Powered subwoofer
Frequency Response (−10dB) 50 - 20000 Hz 45 - 20000 Hz 40 - 20000 Hz 33 - 170 Hz
Max SPL (calculated) 131 dB 133 dB 137 dB 130 dB
LF Driver 12”, 2,5" VC 15”, 2,5" VC 2x15", 2,5" VC 18”, 3" VC
HF Driver 1”, 1,75" VC 1”, 1,75" VC 1”, 1,75" VC
Nominal Coverage Angle
(Horizontal × Vertical)
100° x 50° 100° x 50° 100° x 50°
Amplifier power 500+150 W 500+150 W 800+400 W 650 W
Amplifier
Class D, fan cooling,
DSP with phase-
linear FIR
Class D, fan cooling,
DSP with phase-
linear FIR
Class D, fan cooling,
DSP with phase-
linear FIR
Class D, fan cooling,
DSP
Input sensivity 0 dBV (1 V RMS) 0 dBV (1 V RMS) 0 dBV (1 V RMS) 0 dBV (1 V RMS)
Connectors
XLR input, XLR
output, Powercon
mains
XLR input, XLR
output, Powercon
mains
XLR input, XLR
output, Powercon
mains
XLR input, XLR
output, Powercon
mains
Dimensions (W×H×D) 359x582x344 mm 421x719x400 mm 423x1105x420 mm 552x668x647 mm
Net weight 17,8 kg 22,4 kg 43 kg 42,3 kg
Shipping weight 20,3 kg 24,9 kg 46 kg 45,3 kg
Mounting
10x M10 mounting
points,
35mm adjustable
pole socket
10x M10 mounting
points,
35mm adjustable
pole socket
10x M10 mounting
points
M20 distance pole
adapter
Enclosure material
Plywood; wear-
resistant paint
Plywood; wear-
resistant paint
Plywood; wear-
resistant paint
Plywood; wear-
resistant paint
Grill
Steel grill, polymer
protective net
Steel grill, polymer
protective net
Steel grill, polymer
protective net
Steel grill, polymer
protective net
