USING THE AUDIO/VIDEO INPUT JACKS
T
he TV’s Audio/Video Input jacks are
for direct picture and sound connec-
tions between the TV and a VCR (or
similar accessory device) that has
Audio/Video Output jacks.
Connect one end of the VIDEO
(yellow) CABLE to the AV1 in VIDEO
jack on the back of the TV. Then con-
nect one end the AUDIO (red and
white) CABLES to the AV1 in AUDIO
L and R(left and right) jacks on the rear
of the TV.
Connect other end of the VIDEO
(yellow) CABLE to the VIDEO OUT
jack on the back of the VCR. Then con-
nect the other ends of the AUDIO (red
and white) CABLES to the AUDIO
(left and right) OUT jacks on the rear of
the VCR.
Turn the VCR and the TV ON.
Press the CH + or – buttons on the
remote to scroll the channels until AV1
appears in the upper left corner of the
TV screen.
Slide the TV/VCR/ACC switch to
the VCR position.
Now your ready to place a prere-
corded video tape in the VCR and press
the PLAY 䊳 button
.
