Magnavox MWC13D5 User Manual

WIRING DIAGRAM
T8100WI
1-12-1
DVD MAIN CBA UNIT
FOCUS
SCREEN
GND
D.Y.
HD VD
CN2505
CLN551
CN1601
CL1501
T1571 FBT
CRT
1 2
3 4
5
CN1571
ANODE
CL2501
7 6 4 4 3 2 1
W1601 AC CORD
SP1802 SPEAKER L-CH
CN1801
SP1801 SPEAKER R-CH
CN1802
CL1802 CL1801
GND 2 HEATER 1 +160V 3 GND 4 +8V 5 GREEN 6 RED 7
MAIN CBA
CRT CBA
BLUE 8
GND HEATER +160V GND +8V GREEN RED
8 BLUE

CN9301
1 2
GND TRAY-IN SP(-)
3 4
SL(-)
5
SL(+)
6 SP(+)
TRAY-IN
DRIVE CBA
M
SLED MOTOR
M
SPINDLE MOTOR
PICK UP UNIT
CN201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
TS(+) TS(-) FS(-) CD-LD FS(+) GND(DVD-PD) GND(CD-PD) PD-MONI DVD-LD VREF E GND B DVD-ON+5V CD/DVD D A C F GND(LD)
DETECTOR
FSTS
7 9
11
2 3 6 5 4
SP-ROT 11 SL-AMP 22 SL-ADS 33 GND 44 GND 55 NU 66 GND 77 SPDIF 88
DVD-AUDIO-MUTE 99
DVD-AUDIO(L) 1010 DVD-AUDIO(R) 1111 GND 1212
CN4 CN4A
VREF 11 STBY 22 FD-OFST 33 SLD 44 TD-OFST 55 SPDL 66 GND 77 TS(+) 88 TS(-) 99 FS(+) 1010 FS(-) 1111 GND 1212
CN3A CN3
EV+1.2V 11 EV+1.2V 22 EV+1.2V 33 EV+3.3V 44 EV+3.3V 55 GND 66 GND 77 GND 88
GND 99
GND 1010 NU 1111 NU 1212
CN2A CN2
NU 1313 NU 1414 NU 1515 NU 1616 NU 1717
DVD-ON+3.3V 11 GND 22 GND 33 GND 44 DVD-ON+5V 55 AUDIO+5V 66 PWRCON 77 GND 88
SCLK 99
CS 1010 SDATA 1111 DVD-REMOTE 1212
CN1A CN1
GND 1313 DVD-Y 1414 GND 1515 DVD-C 1616 TRAY-IN 1717
DVD MECHANISM
V501
L551
SP-R 1 SP-GND 2
SP-L 1 SP-GND 2
