ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MAIN CBA UNIT
MMA CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N79T1JUP
Ref. No. Description Part No.
MMA CBA
Consists of the following
1ESA10559
MAIN CBA
CRT CBA
----------
----------
Ref. No. Description Part No.
MAIN CBA
Consists of the following:
----------
CAPACITORS
C1001 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C1002 ELECTROLYTIC CAP. 330µF/6.3V M CE0KMASDL331
C1003 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1004 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1005 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C1006 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1008 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1009 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C1036 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1037 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1039 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1042 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1044 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C1047 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1048 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1052 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C1053A FILM CAP.(P) 0.018µF/50V J CMA1JJS00183
C1203 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1204 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
C1205 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1206 CHIP CERAMIC CAP. B K 220pF/50V CHD1JK30B221
C1207 FILM CAP.(P) 0.001µF/50V J CMA1JJS00102
C1209 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1222 ELECTROLYTIC CAP. 0.1µF/50V M CE1JMASDL0R1
C1223 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1224 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1225 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1231 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1232 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C1234 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1302 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1304 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1305 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1306 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1307 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1308 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1309 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1310 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1311 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1313 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1314 CHIP CERAMIC CAP.(1608) CH D 10pF/50V CHD1JD3CH100
C1316 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1317 STACKED FILM CAP. 0.47µF/50V J CMA1JJS00474
C1318 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1319 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1320 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1324 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C1325 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1335 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1348 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1352 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1552 MYLAR CAP. 0.22µF/50V J CMA1JJS00224
C1553 ELECTROLYTIC CAP. 2.2µF/50V M LL CE1JMASLL2R2
C1555 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C1556 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZPDL102
C1559 ELECTROLYTIC CAP. 330µF/35V M CE1GMASDL331
C1560 FILM CAP.(P) 0.01µF/50V J CMA1JJS00103
C1571 P.P. CAP 0.33µF/200V J CA2D334VC012
C1574 ELECTROLYTIC CAP. 4.7µF/250V M CE2EMASDL4R7
C1577 FILM CAP.(P) 0.022µF/50V J CMA1JJS00223
C1578 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C1580# P.P. CAP 0.0082µF/1.6K J CA3C822VC011
C1584 ELECTROLYTIC CAP. 1µF/160V M CE2CMASDL1R0
C1591 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1592 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1593 ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C1594 ELECTROLYTIC CAP. 47µF/160V M W/F CE2CMZNDL470
C1601# METALLIZED FILM CAP. 0.22µF/250V CT2E224MS037
C1602# METALLIZED FILM CAP. 0.1µF/250V CT2E104MS037
C1605 CERAMIC CAP. BN 560pF/2KV CCD3DKA0B561
C1607 SAFETY CAP. 4700pF/250V KX CA2E472MR050
C1609 FILM CAP.(P) 0.068µF/50V J CMA1JJS00683
C1610# ELECTROLYTIC CAPACITOR 270µF/200V N CA2D271DYG05
C1611 FILM CAP.(P) 0.0012µF/50V J CMA1JJS00122
C1612 FILM CAP.(P) 0.068µF/50V J CMA1JJS00683
C1613 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1615 CERAMIC CAP. BN 680pF/2KV CCD3DKA0B681
C1616# ELECTROLYTIC CAP. 100µF/160V M CE2CMZPDL101
C1617# ELECTROLYTIC CAP. 470µF/35V M CE1GMZPDL471
C1619 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1621 CERAMIC CAP. B K 1000pF/100V CCD2AKS0B102
C1623 FILM CAP.(P) 0.01µF/50V J CMA1JJS00103
C1625 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
Ref. No. Description Part No.
