Table 1 (V501 and L551 Combination)
Note 1: Purity and Convergence Adjustments must be
performed following CRT replacement. Refer to
Electrical Adjustment Instructions.
Note 2: Please confirm CRT Type No. on the CRT
Warning Label which is located on the CRT. Then See
the Table 1 for V501 and L551 combination chart.
Please refer this CRT, Deflection Yoke combination
chart for parts order.
CRT Warning Label Location
V501: CRT Type No. V501: CRT Part No.
L551: Deflection
Yoke Part No.
A34AGT13X TCRT190CP036 LLBY00ZSY005
A34KQW42X TCRT190MS010 LLBY00ZSY002
A34KQW42X TCRT190SM013 LLBY00ZMS027
A34JLL90X(W) TCRT190QS015 LLBY00ZQS001
A34LRQ90X(VW) TCRT190P7003 LLBY00ZQS007
A34KPU02XX TCRT190GS016 LLBY00ZSY002
A34JXV70X TCRT190THA02 LLBY00ZSY002
CRT
CRT Warning Label
CRT Type No.
