1-1-1 T8100SP
SPECIFICATIONS
< TV Section >
*Test input terminal
<Except Tuner>-------------Video input (1Vp-p)
Audio input (-10dB)
<Tuner>-----------------------Ant. input (80dBµV) Video: 87.5%
Audio: 25kHz dev (1kHz Sin)
<DEFLECTION>
<VIDEO & CHROMA>
<TUNER>
Note: Nominal specifications represent the design specifications. All units should be able to approximate these.
Some will exceed and some may drop slightly below these specifications. Limit specifications represent the abso-
lute worst condition that still might be considered acceptable. In no case should a unit fail to meet limit specifica-
tions.
Description Condition Unit Nominal Limit
1. Over Scan — % 90 —
2. Linearity
Horizontal % — ±15
Vertical % — ±10
3. High Voltage — kV 22 —
Description Condition Unit Nominal Limit
1. Misconvergence
Center m/m — 0.4
Corner m/m — 2.1
Side m/m — 1.5
2. Tint Control Range — deg ±30 —
3. Contrast Control Range — dB 12 2
4. Brightness (100% White Full Field) Contrast: Max ft-L 55 40
5. Color Temperature — K 9200 —
Description Condition Unit Nominal Limit
1. Video S/N (80dBµV, TV4ch) — dB 45 40
2. Audio S/N (W/LPF) — dB 45 40
3. Audio Output Power at Speaker — W 1 0.8
To Next Page
