20050425 1-18-2 T8100EL
C1626 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1630 FILM CAP.(P) 0.0056µF/50V J CMA1JJS00562
C1634 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1637 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1639 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1640 ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPDL102
C1650 ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASDLR47
C1654 CERAMIC CAP.(AX) B 0.01µF/50V CCK1JKT0B103
C1662 ELECTROLYTIC CAP. 470µF/16V M CE1CMZPDL471
C1664 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1669 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1670 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C1702 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1704 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1705 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1706 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1731 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1734 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1735 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1736 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1746 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C1748 PCB JUMPER D0.6-P5.0 JW5.0T
C1749 PCB JUMPER D0.6-P5.0 JW5.0T
C1803 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1804 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1805 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1808 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1809 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1810 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1811 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1812 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1814 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMASSL100
C1815 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMASSL100
C1816 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C1817 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C1820 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1851 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMASSL4R7
C1852 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL010
C9280 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C9281 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9284 CHIP CERAMIC CAP.(1608) B K 6800pF/50V CHD1JK30B682
C9288 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C9289 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C9311 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9313 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C9314 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C9315 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9316 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9318 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9324 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9325 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9326 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C9327 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
CONNECTORS
CN1571# CONNECTOR BASE 5P TV-50P-05-V3 J3TVC05TG002
CN1601# CONNECTOR BASE 2P TV-50P-02-V3 J3TVC02TG002
CN1801 STRAIGHT CONNECTOR BASE 00 8283 0212
00 000
J383C02UG002
CN1802 STRAIGHT CONNECTOR BASE 00 8283 0212
00 000
J383C02UG002
CN9301 FMN CONNECTOR TOP 6P 06FMN-BTRK JCFNG06JG002
Ref. No. Description Part No.
DIODES
D1001 PCB JUMPER D0.6-P5.0 JW5.0T
D1201 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1206 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1302 ZENER DIODE MTZJT-7710A QDTA00MTZJ10
D1303 PCB JUMPER D0.6-P5.0 JW5.0T
D1307 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1309# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1311 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1312 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1313 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1318 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1321 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1552 DIODE 1N5397-B NDLZ001N5397
D1571 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D1572# DIODE FR104-B NDLZ000FR104
D1584 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1585 ZENER DIODE MTZJT-775.1B QDTB0MTZJ5R1
D1591# ZENER DIODE MTZJT-7736B QDTB00MTZJ36
D1595# ZENER DIODE MTZJT-7720C QDTC00MTZJ20
D1596# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1597# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1598# DIODE FR104-B NDLZ000FR104
D1601 PCB JUMPER D0.6-P10.0 JW10.0T
D1603# DIODE 1N5399-B/P NDLZ001N5399
D1604# DIODE 1N5399-B/P NDLZ001N5399
D1605# DIODE 1N5399-B/P NDLZ001N5399
D1606# DIODE 1N5399-B/P NDLZ001N5399
D1607# ZENER DIODE MTZJT-7720C QDTC00MTZJ20
D1608 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1609# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1610 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1613 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1614# ZENER DIODE MTZJT-7736A QDTA00MTZJ36
D1616 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1617# DIODE FR154 NDLZ000FR154
D1618 DIODE 15KRA40 QDLZ015KRA40
D1619# DIODE FR104-B NDLZ000FR104
D1620# ZENER DIODE MTZJT-777.5B QDTB0MTZJ7R5
D1621 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1623# DIODE FR154 NDLZ000FR154
D1624 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D1625# RECTIFIER DIODE FR202-B/P NDQZ000FR202
D1626 ZENER DIODE MTZJT-7736A QDTA00MTZJ36
D1627# SCHOTTKY BARRIER DIODE 21DQ04 QDQZ0021DQ04
D1629 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1633 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D1637# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1639 PCB JUMPER D0.6-P10.0 JW10.0T
D1640# DIODE 1ZC36 QDQZ0001ZC36
D1641 ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D1650# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1652# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1653# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1659 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1662 RECTIFIER DIODE ERA15-02 AERA1502****
D1731 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1732 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1801# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC1001 IC VIF/SIF M61113FP QSZBA0SHT019
IC1201# MICRO COMPUTER+VCD M61273M8-067FP QSZAA0RHT073
Ref. No. Description Part No.
