20050425 1-18-3 T8100EL
IC1202 IC MEMORY BR24C02F-W QSMBA0SRM003
IC1551# VERTICAL OUTPUT IC LA78040A QSBBA0SSY003
IC1601# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC1602 VOLTAGE REGULATOR PQ070XF01SZH QSZBA0SSH054
IC1603 IC SHUNT REGULATOR KIA431-AT NSZLA0TJY001
IC1604 IC SHUNT REGULATOR KIA431-AT NSZLA0TJY001
IC1801 IC AN17812A QSZBA0SMS017
IC9202 IC(OPAMP) LM324NSR NSZBA0TTY190
IC9301 ACTUATER DRIVER SA5694 NSZBA0T0S002
COILS
L1031 PCB JUMPER D0.6-P5.0 JW5.0T
L1033 INDUCTOR 18µH-J-26T LLAXJATTU180
L1041 PCB JUMPER D0.6-P5.0 JW5.0T
L1204 PCB JUMPER D0.6-P5.0 JW5.0T
L1301 INDUCTOR 22µH-K-5FT LLARKBSTU220
L1302 PCB JUMPER D0.6-P5.0 JW5.0T
L1557 CHOKE COIL 22µH-K LLBD00PKV006
L1559 PCB JUMPER D0.6-P7.5 JW7.5T
L1601# LINE FILTER ELF15N813AN LLBG00ZMS050
L1615 INDUCTOR 10µH-K-5FT LLARKBSTU100
TRANSISTORS
Q1285 RES. BUILT-IN TRANSISTOR KRA103M NQSZ0KRA103M
Q1301 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1303 TRANSISTOR 2SC2120-O-TPE2 QQS002SC2120
Q1304 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1571# TRANSISTOR TT2138LS-YB11 QQZZ00TT2138
Q1572 TRANSISTOR 2SC1627Y-TPE2 QQSY02SC1627
Q1591# TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1601# MOS FET 2SK3563 QFWZ02SK3563
Q1602# TRANSISTOR 2SC2120-O-TPE2 QQS002SC2120
Q1604# TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1605 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1606# TRANSISTOR 2SA950(O) Q2SA9500TPE2
Q1607 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1608 TRANSISTOR KTC3199(GR) NQS10KTC3199
Q1609 RES. BUILT-IN TRANSISTOR KRC103M NQSZ0KRC103M
Q1610 TRANSISTOR 2SA1175(F) QQSF02SA1175
Q1612 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1613 TRANSISTOR 2SC2120-O-TPE2 QQS002SC2120
Q1614 TRANSISTOR KTC3199(GR) NQS10KTC3199
Q1615 TRANSISTOR 2SD400(F) QQUF002SD400
Q1616 TRANSISTOR 2SC2120-O-TPE2 QQS002SC2120
Q1619 TRANSISTOR KTC3199(GR) NQS10KTC3199
Q1621 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1622 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1623 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1731 TRANSISTOR 2SC2785(F) QQSF02SC2785
Q1732 TRANSISTOR 2SC2785(F) QQSF02SC2785
RESISTORS
R1001 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1002 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1010 CHIP RES.(1608) 1/10W J 200 Ω RRXAJR5Z0201
R1011 CHIP RES.(1608) 1/10W J 47 Ω RRXAJR5Z0470
R1012 CHIP RES.(1608) 1/10W J 150 Ω RRXAJR5Z0151
R1013 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1016 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R1018 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R1019 CHIP RES.(1608) 1/10W J 220k Ω RRXAJR5Z0224
R1022 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1030 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R1031 CHIP RES.(1608) 1/10W J 27k Ω RRXAJR5Z0273
R1037 CHIP RES.(1608) 1/10W J 180 Ω RRXAJR5Z0181
Ref. No. Description Part No.
R1041 CHIP RES.(1608) 1/10W J 56k Ω RRXAJR5Z0563
R1201 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1202 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1203 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1204 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1205 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1206 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1207 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1208 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R1209 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1210 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1211 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1216 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1220 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1221 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1222 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1223 CHIP RES.(1608) 1/10W J 100k Ω RRXAJR5Z0104
R1224 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R1225 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R1229 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1230 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R1231 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1232 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1233 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1234 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1235 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1236 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R1237 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1238 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R1240 CHIP RES.(1608) 1/10W J 1M Ω RRXAJR5Z0105
R1241 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1293 CARBON RES. 1/4W J 47k Ω RCX4JATZ0473
R1294 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1301 CHIP RES.(1608) 1/10W J 180k Ω RRXAJR5Z0184
R1302 CHIP RES.(1608) 1/10W J 15k Ω RRXAJR5Z0153
R1303 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1304 CHIP RES.(1608) 1/10W J 470 Ω RRXAJR5Z0471
R1305 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1306 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R1308 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R1309 CHIP RES.(1608) 1/10W J 39k Ω RRXAJR5Z0393
R1312 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1317 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1320 CHIP RES.(1608) 1/10W J 120k Ω RRXAJR5Z0124
R1321 CARBON RES. 1/4W J 56 Ω RCX4JATZ0560
R1322 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R1323 CHIP RES.(1608) 1/10W J 6.8k Ω RRXAJR5Z0682
R1327 CARBON RES. 1/4W J 22 Ω RCX4JATZ0220
R1328 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R1330 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R1334 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1335 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1336 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1338 CARBON RES. 1/4W J 12 Ω RCX4JATZ0120
R1339 CARBON RES. 1/4W J 1.2 Ω RCX4JATZ01R2
R1346 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R1347 PCB JUMPER D0.6-P5.0 JW5.0T
R1430 CHIP RES.(1608) 1/10W J 3.9k Ω RRXAJR5Z0392
R1544# CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R1551 CHIP RES.(1608) 1/10W J 330 Ω RRXAJR5Z0331
R1552 CARBON RES. 1/4W J 1.5k Ω RCX4JATZ0152
R1556 CARBON RES. 1/4W J 1 Ω RCX4JATZ01R0
R1557 CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
Ref. No. Description Part No.
