Magnavox MWC13D5 User Manual

20050425 1-18-5 T8100EL
CRT CBA
R1752 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1753 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1788 CHIP RES.(1608) 1/10W J 160 Ω RRXAJR5Z0161
R1789 CHIP RES.(1608) 1/10W J 160 Ω RRXAJR5Z0161
R1790 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1791 CHIP RES.(1608) 1/10W J 100 Ω RRXAJR5Z0101
R1801 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1802 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1803 CHIP RES.(1608) 1/10W J 2.7k Ω RRXAJR5Z0272
R1804 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1805 PCB JUMPER D0.6-P5.0 JW5.0T
R1806 PCB JUMPER D0.6-P5.0 JW5.0T
R1807 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R1808 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1809# METAL OXIDE FILM RES. 1W J 15 Ω RN01150ZU001
R1810 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1811 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R1812 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1813 CHIP RES.(1608) 1/10W J 1.8k Ω RRXAJR5Z0182
R1818# METAL OXIDE FILM RES. 1W J 15 Ω RN01150ZU001
R1821 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1822 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R1854 CHIP RES.(1608) 1/10W J 1.5k Ω RRXAJR5Z0152
R1855 CHIP RES.(1608) 1/10W J 5.6k Ω RRXAJR5Z0562
R9270 CHIP RES.(1608) 1/10W J 8.2k Ω RRXAJR5Z0822
R9271 CHIP RES.(1608) 1/10W J 18k Ω RRXAJR5Z0183
R9274 CHIP RES.(1608) 1/10W J 4.7k Ω RRXAJR5Z0472
R9275 CHIP RES.(1608) 1/10W J 6.2k Ω RRXAJR5Z0622
R9276 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R9277 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R9278 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R9279 CHIP RES.(1608) 1/10W J 47k Ω RRXAJR5Z0473
R9280 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
R9281 CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z1002
R9282 CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z1002
R9283 CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z1002
R9284 CHIP RES.(1608) 1/10W F 10k Ω RRXAFR5Z1002
R9285 CHIP RES.(1608) 1/10W J 22k Ω RRXAJR5Z0223
R9286 CHIP RES.(1608) 1/10W J 2.2k Ω RRXAJR5Z0222
R9316 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9317 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9318 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9319 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9320 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9321 CARBON RES. 1/4W J 2.2 Ω RCX4JATZ02R2
R9322 CHIP RES.(1608) 1/10W J 10k Ω RRXAJR5Z0103
R9325 CHIP RES.(1608) 1/10W J 1k Ω RRXAJR5Z0102
SWITCHES
SW1201 TACT SWITCH SKQSAB SST0101AL038
SW1202 TACT SWITCH SKQSAB SST0101AL038
SW1203 TACT SWITCH SKQSAB SST0101AL038
SW1204 TACT SWITCH SKQSAB SST0101AL038
SW1205 TACT SWITCH SKQSAB SST0101AL038
SW1206 TACT SWITCH SKQSAB SST0101AL038
SW1207 TACT SWITCH SKQSAB SST0101AL038
SW1208 TACT SWITCH SKQSAB SST0101AL038
SW1209 TACT SWITCH SKQSAB SST0101AL038
SW1210 TACT SWITCH SKQSAB SST0101AL038
SW1211 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
BC1571 BEAD INDUCTORS FBA04HA600VB-00 LLBF00STU026
BC1602 BEAD INDUCTORS FBR07HA121TB-00 LLBF00ZTU021
Ref. No. Description Part No.
BC1607 PCB JUMPER D0.6-P5.0 JW5.0T
BC1610 BEAD CORE B16 RH 3.5X3X1.3 XL03003XM002
BC1611 BEAD CORE B16 RH 3.5X3X1.3 XL03003XM002
BC1736 PCB JUMPER D0.6-P5.0 JW5.0T
CF1031 CERAMIC TRAP 4.5MHz FBE455PMR003
CF1032 CERAMIC FILTER SFSRA4M50CF00-B0 FBB455PMR004
F1601# FUSE 4.00A/125V PAGU20CAG402
FH1601 FUSE HOLDER MSF-015 XH01Z00LY001
FH1602 FUSE HOLDER MSF-015 XH01Z00LY001
JK1701 RCA JACK(YELLOW) MTJ-032-05B-20 JXRL010LY038
JK1702 RCA JACK(RED) MTJ-032-05A-21 JYRL010LY010
JK1703 RCA JACK(WHITE) MTJ-032-05B-22 JXRL010LY039
JK1730 RCA JACK MSP-241V-05 PBSN W/O JXRL010LY085
JK1801 MINI JACK HSJ2000-01-010 JYSL010HD002
JK2501# CRT SOCKET ISMS02S JSCC220PK003
PS1601# THERMISTOR ZPB45BL7R0A QNZZ45BL7R0A
RS1201 REMOCON RECEIVE UNIT PIC-37042SR USESJRSKK034
SA1601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
SF1001 SAW FILTER SAFHM45M7VAAZ00B03 FBB456PMR010
SG1601# GAP. FNR-G3.10D FAZ000LD6005
T1571# FLYBACK TRANSFORMER JF0501-3101B LTF00CPXB039
T1572 H0RIZONTAL DRIVE TRANS LP2-005 LTH00CPA5005
T1601# SWITCHING TRANS 5717 LTT00CPKT183
TB4 HEAT SINK PKK T8100UA 1EM320174
TB5 HEAT SINK PKD T8100UA 1EM420625
TB8 HEAT SINK PKM T8100UA 1EM420683
TL2 SCREW B-TIGHT D3X8 BIND HEAD+ GBMB3080
TP1304 PCB JUMPER D0.6-P5.0 JW5.0T
TP1305 PCB JUMPER D0.6-P5.0 JW5.0T
TP1401 PCB JUMPER D0.6-P10.0 JW10.0T
TP1402 PCB JUMPER D0.6-P10.0 JW10.0T
TP1403 PCB JUMPER D0.6-P10.0 JW10.0T
TP1404 PCB JUMPER D0.6-P10.0 JW10.0T
TP1405 PCB JUMPER D0.6-P7.5 JW7.5T
TP1501 PCB JUMPER D0.6-P7.5 JW7.5T
TP1502 PCB JUMPER D0.6-P5.0 JW5.0T
TP1503 PCB JUMPER D0.6-P5.0 JW5.0T
TP1731 PCB JUMPER D0.6-P7.5 JW7.5T
TP1732 PCB JUMPER D0.6-P7.5 JW7.5T
TP1733 PCB JUMPER D0.6-P7.5 JW7.5T
TP1734 PCB JUMPER D0.6-P7.5 JW7.5T
TU1001 TUNER UNIT TEFH9-001A UTUNNTUAL042
VR1601# CARBON P.O.T. VZ067TL1 B103 PB(F) VRCB103HH014
W1601# AC CORD A0A0280-002 WAC0162LTE03
WT1 LEAD CLAMPER 100MM 1790356
X1301 XTAL 3.579545 MHz FXD355LLN003
Ref. No. Description Part No.
CRT CBA
Consists of the following:
----------
CAPACITORS
C2501 CERAMIC CAP. B K 1000pF/2KV CCD3DKP0B102
C2511 CHIP CERAMIC CAP. B K 390pF/50V CHD1JK30B391
C2521 CHIP CERAMIC CAP. B K 390pF/50V CHD1JK30B391
C2531A CHIP CERAMIC CAP. B K 470pF/50V CHD1JK30B471
CONNECTOR
CN2505 CONNECTOR PIN 1P RT-01N-2.3A 1730688
COIL
L2501 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q2511 TRANSISTOR 2SC2482 TPE6 QQSZ02SC2482
Ref. No. Description Part No.
