Internal Sensor Locations
Pull back the door which is located inside of the outer door to
obtain access to the below mentioned sensors:
1
2
Door
Outer Door
Figure 13 : How to open the Door.
Urtravilet Sensor
Magnetic Sensor
Magnetic Sensor
Inline Sensors
Inline Sensors
Count Sensors
Figure 14 : Internal Sensor Locations
