3. Lift the coin feeding part assembly, put the coin under
diameter adjusting assembly passage, make sure it has
width difference of 0.2~0.3mm between coin and
passage.
Pic.6.2-3
6.3 Counting sequence for mixed coins
If there are mixed coins on the hopper, you need to count the coins from biggest
diameter to smallest size sequence. You can fix the thickness adjusting knob to
the biggest thickness coin. During the counting, the biggest diameter coins will
be counted out from the coin outlet to the bag, and the smallest diameter coins
will be sorted out to the rejected coin box.
6.4 Coin jamming clearance
If the machine stops to work because of coin jamming, the LED display will
show error code of “Eb0”. Please press CLR key to clear the error code, and then
press START/STOP key to restart counting. If the machine still fails to work,
please do as follows:
(1) Open the side cover;
Pic.6.4-1
