Magner 915 - Technical Specifications; Control Panel Overview

Magner 915 User Manual
2
3. Technical specification
Mode name
MAGNER 915
Hopper capacity
1000~2000pcs
Counting speed
about 1500pcs/min
Countable coin diameter
14~33mm
Countable coin thickness
1.0~3.4mm
Display
5 digits LED
Batch number range
1~9999
Dimension
380*230*180mm
Net weight
8.8kg
Power consumption
60W
Power requirements
220V±10%, 50Hz or 110V±10%, 60Hz
4. Panel
