Magnetek Flex 8 PRO - Status Lights Indicators & Warnings; Push Button Error Table

Enrange Flex EM/EX Instruction Manual
April 2019
Page 15 of 19
5.3 STATUS LIGHTS INDICATORS & WARNINGS
Type
Display Type
Indication
1
Slow green blink
(Normal Operation)
Transmitter on and in standby.
2
Blinking orange
Button has been pressed and the unit is transmitting.
The speed at which the orange LED blinks is directly
related to how far down the button is pressed.
3
1 red blink followed by a
2-second pause
Voltage goes below 1.9V during operation -
change batteries immediately.
4
2 red blinks followed by a
2-second pause
A push button is active while turning on the transmitter.
The button that is active will be designated by the (D, C,
B, A) LEDs. See Section 5.4
5
3 red blinks followed by a
2-second pause
I-CHIP error.
6
4 red blinks followed by a
2-second pause
Transmitting error, system cannot lock on
to the designated channel.
7
Constant green for up to 2
seconds
Transmitter power on with no faults detected (prior to
initiating the START function).
8
Solid Red
Stop command initiated with receiver
E-Stop deactivated.
9
Solid Red
Voltage goes below 1.9V at initial power on - transmitter
power shuts off.
5.4 PUSH BUTTON ERROR TABLE
D
C
B
A
Push Button
OFF
OFF
OFF
ON
1
OFF
OFF
ON
OFF
2
OFF
OFF
ON
ON
3
OFF
ON
OFF
OFF
4
OFF
ON
OFF
ON
5
OFF
ON
ON
OFF
6
OFF
ON
ON
ON
7
ON
OFF
OFF
OFF
8
ON
OFF
OFF
ON
9
ON
OFF
ON
OFF
10
ON
OFF
ON
ON
11
ON
ON
OFF
OFF
12
