IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 15 of 54
Magnetek, Inc.
Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
Series 3 2145
R/L1, S/L2, T/L3,
U/T1, V/T2, W/T3, -,
+1, R1/L11, S1/L21,
T1/L31
M10
17.6 to 22.5
(154.8 to 197.9)
─ 4/0
+3 M8
8.8 to 10.8
(77.4 to 95.0)
──
M10
17.6 to 22.5
(154.8 to 197.9)
─ 2
r/ 1, / 2
M4
1.3 to 1.4
(11.4 to 12.3)
─ 16
Series 4 2145
R/L1, S/L2, T/L3,
U/T1, V/T2, W/T3
M10
18 to 23
(159 to 204)
2/0 to 4/0, 3/0 to 4/0
(T1-3)
1/0 to 2/0
-, +1 M10
18 to 23
(159 to 204)
1 to 4/0 ─
+3 M10
18 to 23
(159 to 204)
1/0 to 4/0 ─
M10
18 to 23
(159 to 204)
4 to 2 4
Series 4 2180
R/L1, S/L2, T/L3 M10
18 to 23
(159 to 204)
1/0 to 2/0 1/0 to 2/0
U/T1, V/T2, W/T3 M10
18 to 23
(159 to 204)
1/0 to 2/0 1/0 to 2/0
-, +1 M10
18 to 23
(159 to 204)
1 to 4/0 ─
+3 M10
18 to 23
(159 to 204)
1/0 to 4/0 ─
M10
18 to 23
(159 to 204)
4 to 1/0 4
Series 3 2215
R/L1, S/L2, T/L3,
-, +1
M10
17.6 to 22.5
(154.8 to 197.9)
─
250
2-2/0
U/T1, V/T2, W/T3,
R1/L11, S1/L21,
T1/L31
M10
17.6 to 22.5
(154.8 to 197.9)
─
250
2-2/0
+3 M8
8.8 to 10.8
(77.4 to 95.0)
──
M10
17.6 to 22.5
(154.8 to 197.9)
─ 4
r/ 1, / 2
M4
1.3 to 1.4
(11.4 to 12.3)
─ 16
Series 4 2215
R/L1, S/L2, T/L3 M12
32 to 40
(283 to 354)
3/0 to 300
250
2-2/0
U/T1, V/T2, W/T3 M12
32 to 40
(283 to 354)
3/0 to 300
250
2-2/0
-, +1 M12
32 to 40
(283 to 354)
3/0 to 300 ─
+3 M10
18 to 23
(159 to 204)
2 to 300 ─
M12
32 to 40
(283 to 354)
3 to 300 4
IMPULSE
®
•G+ & VG+ Terminal Signal Terminal Screw
Tightening
Torque
N. m (lb.in.)
Possible Gauges
(AWG/kcmil)
Recommended
Gauge (AWG/
kcmil)
