IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 7 of 54
Magnetek, Inc.
Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
Rated
Input Voltage
G+ Series 3
Drive Model
Number
(-AFG+/FVG+)
Heavy Duty G+ Series 4
Drive Model
Number
(-G+/VG+S4)
Heavy Duty
Rated Output
Current (Amps)
Nominal HP
Rated Output
Current (Amps)
Nominal HP
460V,
3-
4001 1.8 0.5 4001 1.8 0.5
4002 2.1 1.0 4003 3.4 1.0
4003 3.7 2.0 4004 4.8 2.0
4005 5.3 3.0 4005 5.5 3.0
N/A N/A N/A 4007 7.2 5.0
4008 8.7 5.0 4009 9.2 5.0
4012 12.5 7.5 4014 14.8 7.5
4017 17 10 4018 18 10
4024 24 15 4024 24 15
4031 31 20 4031 31 20
4039 39 25 4039 39 25
4045 45 30 4045 45 30
4060 60 40 4060 60 40
4075 75 50 4075 75 50
4091 91 60 4091 91 60
4112 112 75 4112 112 75
4150 150 100 4150 150 100
4180 180 125 4180 180 125
N/A N/A N/A 4216 216 150
4260 260 150 4260 260 200
4304 304 250 4304 304 250
4370 370 300 4370 370 300
4477 477 350 4450 450 350
4590 590 500 4605 605 500
