Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 6 of 54
Magnetek, Inc.
1.3 Ratings Summary
The following table summarizes the output current ratings for the G+ Series 4 and G+ Series 3 with respect to the
specific drive model.
Rated
Input Voltage
G+ Series 3
Drive Model
Number
(-AFG+/FVG+)
Heavy Duty G+ Series 4
Drive Model
Number
(-G+/VG+S4)
Heavy Duty
Rated Output
Current (Amps)
Nominal HP
Rated Output
Current (Amps)
Nominal HP
230V,
3-
N/A N/A N/A 2003 3.2 0.5
N/A N/A N/A 2005 5.0 0.75
2007 7.0 1.0 2007 6.9 1.0
N/A N/A N/A 2008 8.0 2.0
2009 9.6 2.0 2011 11 2.0
N/A N/A N/A 2014 14.0 3.0
2015 15.2 3.0 2017 17.5 3.0
2023 23 5.0 2025 25 5.0
2031 31 7.5 2033 33 7.5
2045 45 10 2047 47 10
2058 58 15 2060 60 15
2071 71 20 2075 75 20
2085 85 30 2085 85 30
N/A N/A N/A 2115 115 40
2145 145 50 2145 145 50
N/A N/A N/A 2180 180 60
2215 215 75 2215 215 75
2283 283 100 2283 283 100
2346 346 125 2346 346 125
N/A N/A N/A 2415 415 150
