Magnetek Impulse VG+ series 4 Product Guide

Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 22 of 54
Magnetek, Inc.
Series 4
4216
R/L1, S/L2, T/L3 M10
18 to 23
(159 to 204)
—
250
2-2/0
U/T1, V/T2, W/T3 M10
18 to 23
(159 to 204)
—
250
2-2/0
-, +1 M10
18 to 23
(159 to 204)
——
+3 M10
18 to 23
(159 to 204)
— 4/0
M10
18 to 23
(159 to 204)
— 2
Series 3 4260
R/L1, S/L2, T/L3,
-, +1, R1/L11,
S1/L21, T1/L31
M10
17.6 to 22.5
(154.8 to 197.5)
─
350
2-3/0
U/T1, V/T2, W/T3, M10
17.6 to 22.5
(154.8 to 197.5)
─
350
2-3/0
+3 M8
8.8 to 10.8
(77.4 to 95.0)
──
M12
31.4 to 39.2
(276.2 to 344.8)
─ 2
r/ 1,
200
/
2
200, 400/
2
400
M4
1.3 to 1.4
(11.4 to 12.3)
─ 16
Series 4 4260
R/L1, S/L2, T/L3 M12
32 to 40
(283 to 354)
2/0 to 600
350
2-3/0
U/T1, V/T2, W/T3 M12
32 to 40
(283 to 354)
2/0 to 600
350
2-3/0
-, +1 M12
32 to 40
(283 to 354)
3/0 to 600 ─
+3 M10
18 to 23
(159 to 204)
1 to 325 ─
M12
32 to 40
(283 to 354)
2 to 350 2
Series 3 4304
R/L1, S/L2, T/L3,
-, +1, R1/L11,
S1/L21, T1/L31
M12
31.4 to 39.2
(276.2 to 344.8)
─
350
2-4/0
U/T1, V/T2, W/T3, M12
31.4 to 39.2
(276.2 to 344.8)
─
350
2-4/0
+3 M8
8.8 to 10.8
(77.4 to 95.0)
──
M12
31.4 to 39.2
(276.2 to 344.8)
─ 2
r/ 1,
200
/
2
200, 400/
2
400
M4
1.3 to 1.4
(11.4 to 12.3)
─ 16
IMPULSE
®
•G+ & VG+ Terminal Signal Terminal Screw
Tightening
Torque
N. m (lb.in.)
Possible Gauges
(AWG/kcmil)
Recommended
Gauge (AWG/
kcmil)
