Magnetek Impulse VG+ series 4 Product Guide

Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 24 of 54
Magnetek, Inc.
Series 4 4450
R/L1, S/L2, T/L3 M12
32 to 40
(283 to 354)
3/0 to 300
500
2-300
4-3/0
U/T1, V/T2, W/T3 M12
32 to 40
(283 to 354)
3/0 to 300
500
2-300
4-3/0
-, +1 M12
32 to 40
(283 to 354)
1/0 to 300 ─
+3 M12
32 to 40
(283 to 354)
1/0 to 300 ─
M12
32 to 40
(283 to 354)
1/0 to 300 1/0
Series 3 4590
R/L1, S/L2, T/L3 M16
78.4 to 98
(693.9 to 867.4)
─ 4-250
R1/L11, S1/L21,
T1/L31
M16
78.4 to 98
(693.9 to 867.4)
─ 4-250
U/T1, V/T2, W/T3 M16
78.4 to 98
(693.9 to 867.4)
─ 4-250
-, +1 M16
78.4 to 98
(693.9 to 867.4)
─ 400×4P
+3 M16
78.4 to 98
(693.9 to 867.4)
──
M16
78.4 to 98
(693.9 to 867.4)
─ 1/0
r/ 1, 200/
2
200, 400/
2
400
M4
1.3 to 1.4
(11.4 to 12.3)
─ 16
Series 4 4605
R/L1, S/L2, T/L3,
U/T1, V/T2, W/T3
M12
32 to 40
(283 to 354)
4/0 to 300
2-400
4-250
4-3/0
-, +1 M12
32 to 40
(283 to 354)
1/0 to 300 ─
+3 M12
32 to 40
(283 to 354)
1/0 to 300 ─
M12
32 to 40
(283 to 354)
2/0 to 300 2/0
IMPULSE
®
•G+ & VG+ Terminal Signal Terminal Screw
Tightening
Torque
N. m (lb.in.)
Possible Gauges
(AWG/kcmil)
Recommended
Gauge (AWG/
kcmil)
