MAGUIRE Weigh Scale Blender 4088 TSC User Manual

17
Model Selection
Controllers are programmed to control all sizes of Weigh Scale Blenders. The MODEL number
that your unit is set for will be displayed across the status bar of the controller's Home Screen.
All Weigh Scale Blender controllers come from factory pre-configured for the model blender they
are attached to. If a new blender controller is installed on a blender of a different model, the
controller model may be changed to match the blender. There are 8 main model categories,
each with at least one sub model. The model of the blender can be found on the red serial tag
attached to the blender frame. The possible models are:
Blender Model Batch Weight
(Grams)
Weigh Bin Dimensions (DxWxH)
Load Cell Rating
mm
Inches
MB / MB1 / MB2
400
127x127x127
5” x 5” x 5”
1 @ 3Kg
140 / 140R / 140MP
1000
254x153x153
6” x 10” x 6”
1 @ 3Kg
220 / 240 / 240R / 260
2000
254x254x178
10” x 10” x 7”
2 @ 3 Kg
420 /
440 / 440R / 460
4000
254x254x254
10” x 10” x 10”
2 @ 10 Kg
940 / 950 / 960
9000
407x407x305
16” x 16” x 12”
2 @ 10 Kg
1840 / 1860
18000
407x407x432
16” x 16” x 17”
2 @ 20 Kg
2400
24000
560x508x458
22” x 20” x 18”
2 @ 20 Kg
3000
30000
407x407x432
20” x 22” x 30”
2 @ 20 Kg
“R” Models have 2 removable hoppers
