MAHA PTI Tool - Specifications; 2 Initial Operation; Connection Overview

4
BAZ72501-en
Pos: 11 /Techn ische Dokument ation/Alle Ger äte/Übersc hriften/ Überschrifte n 1.1/T/Über schrift 1.1: Tech nische Daten @ 7\mod_1184075526343_75.docx @ 99711 @ 2 @ 1
1.2
Specifications
Pos: 1 2 /Tec hn ische Dokum ent ation/ Leist ungs prüfs tänd e, Diag nos e-/Ab gas gerä te/ Z7 Z ube hör all gem ein/ 250 1 MAH A PTI To ol/B A/In hal t: Z 725 Tec hnis che Da ten ( Tab ell e) @ 31\m od _136 437 929 432 8_ 75.d ocx @ 1 732 803 @ @ 1
Power supply
Nominal voltage +12 VDC via female OBD connector
Voltage range +8…+36 VDC, max. 3 W
LED Battery CR2032 lithium battery, 3 V
Temperature
Operating temperature 0 °C…+40 °C
Transport temperature -20 °C…+60 °C
Humidity 10...90 % (non condensing)
Housing
Weight approx. 120 g
Dimensions (L x W x H) 121.5 x 50 x 25 mm
Interfaces
Personal Computer (PC) Female USB 1.1 Mini-B connector
Vehicle Male OBD connector (16 pin)
Supported vehicle protocols OBD-compliant and manufacturer-specific protocols
Pos: 13 / Techn ische Dokument ation/ Alle Ger äte/Über schr iften/ Überschri ften 1/I/Über schr ift 1: Inbe trieb nahme @ 23\mod_1301477548701_75.docx @ 987803 @ 2 @ 1
2
Initial Operation
Pos: 14 /Techn ische Dokument ation/Alle Ger äte/Übersc hriften/ Überschrifte n 1.1/A/Übersc hrift 1.1: Ansc hlussübersi cht @ 11\mod_1228992841316_75.docx @ 278616 @ 2 @ 1
2.1
Connection Overview
Pos: 1 5 /Tec hn ische Dokum ent ation/ Leist ungs prüfs tänd e, Diagnos e-/ Abgas ger ät e/Z7 Zub eh ör a llgem ei n/2 501 M AHA P TI T ool/ BA/ Inh alt: Z 72 5 A nsc hluss über s icht ( Le gend e) @ 3 1\mod _1 365 774588417_75.docx @ 1747609 @ @ 1
A
Female USB connector
H
LED button
B
Cover
I
USB cable
C
Blue LED
J
Vehicle female OBD connector
D
Green/red/yellow LED
K
Extension cable (optional)
F
LED in male OBD connector
L
Bluetooth stick
G
Male OBD connector
M
PC
