90
SPECIFICATIONS
Model: 4510
ENGINE
Four strokes, Direct injection, water-cooled
Diesel Engine.
Model :4A220-DY
No. of cylinders :4
Swept Volume :133.656 in³(2,197cc)
Bore :3.42 in
Stroke :3.64 in
Compression Ratio :22:1
Horse Power (HP) :45/2600 rpm
(Manufacturing rating)
Rated Speed :2,600 rpm
High idle rpm :3,000 rpm
Low idle rpm :700 to 750
Fuel injection pump :Throttle type
Cylinder sleeve :Dry
Air Cleaner : Dry Filter element,
paper element filtering type.
Exhaust Muffler : Horizontal Round.
Firing order : 1-3-4-2
Accelerator : Hand & Foot Accelerator
ELECTRICAL STARTING AND LIGHTING
Battery Capacity : 12 Volt 110AH
Starter :Solenoid Engaged.
Key Start with Safety ,
starter switch
Alternator :12V 50A
Instrumentation :Water Temperature Gauge,
Taco meter, Hour meter,
Electrical fuel level gauge.
Lighting: Head lights, side indicators,
Rear parking,, brake &
indicator light, Front
parking & indicator light,
On dash board indicators
for battery charging, turn
signal, PTO signal, Engine
oil pressure, Preheat signal.
CLUTCH
Type : Dry single plate
Outer dia. X Inner dia. : 10.26 X 6.69″
TRANSMISSION
Type : synchro mesh
No. of gears :16 forward,
16 reverse gears
with high and low
selection lever with
Differential Lock
STEERING : Hydraulic power
(Power steering)
POWER TAKE OFF
Rear mounted : 6 splines
Diameter : 1⅜ in.
Standard PTO : ①540@2,391 engine RPM
BRAKES
Foot operated, independent with provision of
inter lock for simultaneous operation. A foot
brake is fitted for parking.
Disc Diameter :7.24 in
Number of lining :5.5 each side
Total brake thickness : 2.299 in
HYDRAULIC SYSTEM
Independent fully”Live”hydraulic pump
and separate reservoir.Position controls with
isolating & response control
Working Pressure :15697KPA(2,275psi)
Max.Lifting Force at
Lower Link hitch point :2,867 lbs(1,300Kg)
Pump
output :Main:9.6GPM(36.4LPM)
Steering:4..46GPM(16.9LPM)
3 point linkage : category 1
adjustable outside
check chains.
