Check batteryLow voltageSlip during rotationSlip
ReplacemalfunctionNo defect wire
AdjustClutch gap largeEngaged to push
with hand
Check wireWire defectEngaged sometimesDisengage
Control the
compressor
direction
Interference with
pulley
Regular noise
Irregular noise
Noise3. Clutch
Check,tightenAir volume control
switch failure
MotorUnable to
control the fan
Check,tightenDuct leakageAir leakage
ReplaceWire cut
ReplaceMotor failureMotor is abnormal
Motor is abnormal ReplaceMotor failure
ReplaceCompressor
ReplaceMalfunction
CleanOil stick at clutch
Check batteryLow voltage
Replace the switchVentilator switch
damage
Controlling
minimum pressure
Evaporator freezing
Air inlet clogged
CAUSE
RemoveMotor is normalWeak from
pressure or
don”t work
2.Motor
REMEDYCONDITIONSYMPTOM
(2) How to check the air conditioning system with the needle of high low gauge
To connect with manifold pressure gauge can find the cause of air conditioning system.
Because manifold pressure gauge is various sensibly (Ambient Temp. is based on 30~35℃)
Caution:
Operating E/G RPM 1500~2000 is must, and so to that you can check the correct cause
and air conditioning.
(In case below the figure of indicated pressure gauge has some clearance, confirm with approximate
indicated needle data.)
Gauge pressure conversion
● lb/in²=PSI
●1 kg/㎠=14,223 in²
(Ex) 200 PSI=14 kgf/㎠
88
