SAFETY/DECALS
14
WARNING: Rollover protection is provided only with proper assembly. Lock pins, must be in
place. Correct parts may be obtained from your dealer.
SECOND POSITION
Remove the lock pin from the position pin.
While holding the ROPS bar CAREFULLY
remove the position pins.
Down the ROPS bar slowly from the second
position.
While holding the ROPS bar carefully install
the position pins.
Install the lock pin to the position pin.
STORED POSITION
Adjustment of Foldable ROPS.
If you feel less friction when the ROPS is
at the upright position , tighten the Lock
Nut until you feel the right friction in the
movement.
STEP6
STEP7
STEP8
STEP9
POSITION PIN
POSITION PIN
POSITION PIN
POSITION PIN
LOCK PIN
LOCK PIN
LOCK NUT

Mahindra 3016 Specifications

General

Engine Power	30 HP
Engine Cylinders	3
Drive Type	4WD
Engine Type	Diesel
Tire Size (Front)	7-16
Transmission	8 Forward / 2 Reverse
Fuel Tank Capacity	32 L
Tire Size (Rear)	12.4-24
