Mahindra 3016 - INDICATOR LAMPS AND SIGNALS

INSTRUMENT/CONTROLS
24
2. ENGINE COOLANT TEMPERATURE GAUGE
3. FUEL GAUGE
4. TURN SIGNAL INDICATORS
The gauge indicates the coolant temperature
when the starter key switch is in ON position.
If the engine overheats, the pointer moves
turns the up side into position area. In this
case, stop the engine immediately and check
for the cause.
The meter shows how much fuel is in the
tank.
NOTE: The pointer can be in lowest position
when the starter key switch is in the OFF
position.To get a fuel level indication, turn the
starter key switch to the ON position.
The LH indicator on the TACHOMETER will
operate when the turn signal switch is turned
to the left. The RH indicator will operate when
the switch is turned to the right.
Both indicators will operate ON and OFF
when hazard switch is pushed down.
TURN SIGNAL
