5. ENGINE GLOW PLUG INDICATOR
6. CHARGE INDICATOR
7. ENGINE OIL PRESSURE INDICATOR
8. INDEPENDENT PTO CLUTCH INDICATOR (Gear Drive Only)
9. HIGH BEAM INDICATOR
This signal indicates the correct functioning of the glow plug circuit.
When the glow plugs have reached the correct temperature for
engine starting, the glow plug indicator lamp will be turned off.
The charge indicator shows the battery is being discharged. If the
lamp illuminates during operation, stop the engine and check for
the cause.
The engine oil pressure indicator shows low engine oil pressure. If
the engine oil pressure drops below its normal pressure, the engine
oil pressure indicator will turn on. Shut off the engine immediately.
Check for the cause.
This signal indicates the INDEPENDENT PTO CLUTCH is ON or
OF F.
This signal indicates the head light high beam is ON or OFF.
The INDICATOR illuminates when the head light is on high beam
position.
