► CHANGING OIL IN THE FRONT AXLE
1. Drain the oil from the center diff plug and the drain
plug in each drive.
2. Replace and tighten all drain plugs.
3.Remove the top plug (Vent plug) from each final drive to
vent air from final drives.
4. Remove the dip stick from the filter hole and fill with
4.33 US gal (16.4 liters) and allow time for the oil to
drain into the final drives.
5. Check the oil level with the dipstick and replace the
vent plugs on both final drives and tighten.
Level gauge & Oil Filler
Some operators have found that when they fill with the correct amount of oil and
check it, the oil level on the dipstick is too high due to the fact that it takes a while for
the
oil to run into the final drives
Im
rtant
Front axle Oil Drain Plug
CLEANING AND CHANGING FILTERS
► ENGINE OIL FILTER
.
Opening the Vent plugs helps to speed this up.
Using a filter wrench turn the filter counter clockwise to
remove it. Lightly smear the rubber seal on the new
filter with oil to secure, turn it clockwise until the seal
contacts the base and then turn it another 2/3 turn to
tighten it.
69
