mBot Class mBot Add-On Pack
Light-Emitting Cat
Light-Emitting Cat
Firstly,you should adjust servo to 90 degrees with software, then
install servo arm to the servo (pay attention to their angle).
Step 1
Step 2
M4×25mm Brass Stud ×2
M4×8mm Screw ×2
9g Micro Servo ×1
9g Micro Servo Bracket ×1
Servo Arm ×1
M2×10mm Screw ×2
M2 Nut ×2
M2.2×6.5mm
Self-drilling Screw
×1
If your mBot already has an mCore case,
please keep it for later construction.
mBot Servo Pack- Light-Emitting Cat
