Makeblock mBot Servo Pack

To Next Page

To Previous Page

20 21

Step 3

Step 4

Bracket 3×3 ×1

M2.2×8mm

Self-drilling Screw

×2

Plastic Spacer 4×7×2mm ×2

Me RGB LED Module ×1

M4×8mm Screw ×2

M4 Nut ×2

Please insert self-drilling

screw through the hole

marked red.

Step 5

Step 6

M4×8mm Screw ×2

M4×8mm Screw ×1

M4 Nut ×1

Me RJ25 Adapter Module ×1

If these two holes on your

mBot are without thread,

please fix the parts with M4

nuts.

Tip

Makeblock mBot Servo Pack - M4×8 Mm
