22 23
Step 7
M4×8mm Screw ×2
Step 8 Wire connections
This is the reference picture of wire connections in construction
examples. You can also change the ports according to your own
program.
Good job !
You have finished the
construction. Now you can
control your Light-Emitting Cat
according to the constructions
on page 5.
Me Line-follower Sensor
9g Micro Servo
Me Ultrasonic Sensor
Me RJ25 Adapter Module
Me RGB LED Module
