16 17
Step 7
M4×8mm Screw ×2
If these two holes on your mBot are without
thread, please fix the parts with M4 nuts.
Step 8 Wire connections
This is the reference picture of wire connections in construction
examples. You can also change the ports according to your own
program.
Good job !
You have finished the construction.
Now you can control your
Head-Shaking Cat according to the
constructions on page 5.
Me Line-follower Sensor
9g Micro Servo
Me Ultrasonic Sensor
Me RJ25 Adapter Module
Me RGB LED Module
Tip
To Next Page
