Upgrade Parts List for mBot
Sensor Bumper Upgrade
1 x M3X12mm Bolt – Ultrasonic
1 x M3 Nut – Ultrasonic
4 x M3X10 mm Bolts – Light Sensors
4 x M3 Nuts - Light Sensors
2 x M5X8mm Bolts – Face Plate
2 x Makeblock Light Sensors
1 x Makeblock Ultrasonic Sensor
1 x 3D Printed Bumper
Handle Frame Upgrade
2 x M4X30mm Bolts – Bumper
4 x M4 Nuts – Bumper
2 x M4X16mm Bolts – Rear of Handles
2 x M4 Nylocs – Rear of Handles
2 x M3X16mm Bolts – Top of Handles
2 x M4X16mm Bolts – Bumper
2 x 3D Printed Handles
Name Plate & LED
Matrix Upgrade
4 x M3X10mm Bolts – LED Matrix
2 x M3 Washers – LED Matrix
4 x M3X12mm Bolts – Name plate
1 x LED Matrix
1 x Acrylic Name Plate
Claw Arm Upgrade
4 x M3X8mm Bolts – Servos
2 x M2 Washers – Servos
2 x M2X10mm Bolts – Servos
4 x M3X40mm Bolts – Claws
2 x M3X16mm Bolts – Claws
2 x M3 Washers
2 x Small Metal Geared Servos
1 x Servo Reverser
1 x Set of 4 3D Printed Claws
8 x M4 Washers – Rear Mass
1 x M4X20mm Bolt – Rear Mass
