Petrol Brushcutter
EBH341U/EBH341L
Important:
Read this instruction manual carefully before putting the Petrol Brushcutter into operation and strictly observe
the safety regulations!
Preserve instruction manual carefully!
EBH341U EBH341L
ORIGINAL INSTRUCTION MANUAL

Table of Contents

Other manuals for Makita EBH341L

Preview: Instruction Manual
Instruction Manual96 pages

Questions and Answers

  • T
    Tyler HillSep 8, 2025
    Why does my Makita EBH341L engine stop soon after starting and not reach full speed?
    • M
      Mr. Robert WilliamsSep 8, 2025
      Your Makita Brush Cutter might be stopping soon after starting, or failing to reach full speed, due to several reasons. Ensure you've warmed up the engine sufficiently. Check that the choke lever is set to “OPEN” after the engine warms up. A clogged fuel filter or a contaminated air cleaner can also cause these issues, so clean them. If these steps don't resolve the problem, the carburetor or drive system may be abnormal.
  • J
    Jose ClarkAug 23, 2025
    Why won't my Makita EBH341L Brush Cutter engine start?
    • H
      Henry BarrettAug 23, 2025
      If the engine of your Makita Brush Cutter doesn't start, several factors could be at play. First, ensure you're operating the primer pump correctly by pushing it 7 to 10 times. Check that you are pulling the starter rope strongly enough. Verify that there is enough fuel in the tank and that the fuel filter isn't clogged. Inspect the fuel tube for any breaks and straighten it if necessary. Replace deteriorated fuel with fresh fuel, ideally every month. If there's excessive fuel suction, adjust the throttle lever from medium to high speed and pull the starter handle. Also, make sure the plug cap is securely attached and the spark plug is clean and properly gapped. If issues persist, the carburetor or drive system may be abnormal, requiring professional inspection and maintenance.
  • K
    Kimberly MorenoAug 25, 2025
    What to do if the cutter blade does not rotate on my Makita EBH341L?
    • J
      Joseph JohnsonAug 25, 2025
      If the cutter blade on your Makita Brush Cutter isn't rotating, stop the engine immediately. Ensure the cutter blade-tightening nut is securely tightened. Also, check for any twigs or foreign matter caught by the cutter blade or dispersion-preventing cover and remove them. If the issue persists, there may be an abnormal drive system, and you should request an inspection and maintenance.
  • M
    michaelbarnesAug 27, 2025
    Why does my Makita EBH341L Brush Cutter engine stop soon or not increase speed?
    • C
      Christopher WilliamsAug 27, 2025
      If your Makita Brush Cutter's engine stops soon after starting or the engine speed doesn't increase, it could be due to several reasons. Make sure to perform a proper warm-up operation. Ensure the choke lever is set to the 'OPEN' position once the engine is warmed up. Check and clean the fuel filter if it's clogged. Also, inspect the air cleaner for contamination or clogs and clean it. If these steps don't resolve the issue, the carburetor or drive system may be abnormal, requiring professional inspection and maintenance.
  • M
    michaelhuynhAug 27, 2025
    What causes abnormal vibration in my Makita EBH341L?
    • R
      Rebecca MarquezAug 27, 2025
      If your Makita Brush Cutter is vibrating abnormally, stop the engine immediately. Check the cutter blade for any damage such as being broken, bent, or worn, and replace it if necessary. Ensure the cutter blade-tightening nut is securely tightened. Verify that the convex part of the cutter blade and cutter blade support fitting are correctly attached. If the vibration continues, there might be an issue with the drive system, requiring professional inspection and maintenance.
  • C
    Christopher ScottSep 22, 2025
    Why is my Makita Brush Cutter main unit vibrating abnormally?
    • O
      odonnellconnieSep 22, 2025
      Abnormal vibration in your Makita Brush Cutter can stem from several issues: * A broken, bent, or worn cutter blade, which should be replaced. * A loosened cutter blade-tightening nut, which needs to be securely tightened. * Also, check the convex part of cutter blade and cutter blade support fitting, and attach securely if shifted. * If the problem continues, the drive system may be abnormal, requiring inspection and maintenance.
  • S
    Scott KingSep 16, 2025
    What to do if my Makita Brush Cutter engine stops soon after starting?
    • V
      valenzuelaaliciaSep 16, 2025
      If your Makita Brush Cutter engine stops shortly after starting, consider the following: * Ensure you perform a proper warm-up operation. * Check that the choke lever is set to “OPEN” once the engine is warmed up. * A clogged fuel filter or a contaminated air cleaner can also cause this issue; clean them. * If the problem persists, it could be an issue with the carburetor or drive system, requiring professional inspection and maintenance.
  • K
    kellybakerSep 18, 2025
    What to do if the cutter blade does not stop immediately on my Makita EBH341L Brush Cutter?
    • R
      robinsonjasonSep 18, 2025
      If the cutter blade on your Makita Brush Cutter doesn't stop immediately, it could be due to: * High idling rotation, which requires adjustment. * A detached throttle wire, which needs to be securely attached. * If these steps don't resolve the issue, there may be an abnormal drive system, and it is recommended to request inspection and maintenance.
  • C
    crosbykyleSep 7, 2025
    How to start a Makita Brush Cutter when the engine won't start?
    • K
      Kevin GrimesSep 7, 2025
      If your Makita Brush Cutter's engine isn't starting, there are several potential causes. First, ensure you're operating the primer pump correctly by pushing it 7 to 10 times. Check that you're pulling the starter rope strongly enough. Make sure the fuel tank isn't empty and that the fuel filter isn't clogged—clean it if it is. Inspect the fuel tube for breaks and straighten it if necessary. If the fuel is old, replace it (recommended every month). If there's excessive fuel suction, set the throttle lever to high speed and pull the starter handle. Also, check that the plug cap is securely attached, the spark plug is clean, and the spark plug clearance is correctly adjusted. If these steps don't work, consider cleaning or replacing the spark plug.
  • M
    Mr. Eric BakerSep 4, 2025
    What causes the metal blade on my Makita Brush Cutter to not stop immediately?
    • P
      Peggy HaysSep 4, 2025
      If the metal blade on your Makita Brush Cutter doesn't stop immediately after you stop the engine, try to adjust the idling rotation. Also, make sure that the throttle wire is securely attached. If the issue persists, request professional inspection and maintenance for potential drive system problems.

Summary

Safety Instructions

General Instructions

General safety advice for operating the brushcutter.

Intended Use of the Machine

Personal Protective Equipment

Details essential protective gear required for safe operation.

Starting Up the Brushcutter

Procedures and checks before beginning operation.

Method of Operation

General Operation Rules

Best practices for safe and effective brushcutter operation.

Cutting Tools

Kickback (Blade Thrust)

Explanation of kickback and how to prevent it.

Maintenance Instructions

General Maintenance

Overview of regular maintenance tasks for longevity and safety.

Before Start of Operation

Inspection and Refill of Engine Oil

Procedure for checking and adding engine oil before use.

Refueling

Handling of Fuel

Points in Operation and How to Stop

Starting

Step-by-step guide for starting the brushcutter.

Stopping

Procedures for safely stopping the engine and the cutting head.

Resharpening the Cutting Tool

Cutter Blade

Nylon Cutting Head

Servicing Instructions

Daily Checkup and Maintenance

Replacement of Engine Oil

Makita EBH341L Specifications
