Makita LC1230 Technical Information

Makita
Model No.
LC1230
Input(w)
1,750
No load speed(rpm)
85x85mm
(3-5/16"x3-5/16")
ø90mm
(3-1/2")
No tools are required Tools are required
1,300
Blade diameter
305mm(12")x25.4mm(1")
Max. cutting
capacities
Adjustment of the fence
angle
Quick vise
150x75mm
(5-7/8"x2-15/16")
100x100mm
(3-15/16"x3/15/16")
ø115mm
(4-1/2")
45 °
90 °
Shaft lock
Double insulation
Net weight
Net weight ----- without power supply cord and blade
Greasing
The movable parts and the ones contacting with the movable parts have to be greased before mounting.

Dismounting of blade case, and gear housing R
Chip saw blade and safety cover have to be taken away.
1. Down the motor unit (motor hausing and blade case) to the base, and lock it with the chain on the
hanger of handle.
2. Dismount the link plate after taking off the pan head screw M6.
3. Dismount the blade case, and then gear housing R.
Mounting of blade case and gear housing R
Carry out the above process in the inverse order.
Blade case
Link plate
Pan head screw M6
Yes
Yes
Yes
19.0kg
(41.9lbs)
17.0kg
(37.5lbs)
Comparision
Repair
Note
LC1210

Makita LC1230 Specifications

General

Blade bore	25.4 mm
Blade diameter	304.8 mm
Idle speed (max)	1300 RPM
Sound power level	115 dB
Cutting depth (45º)	88.9 mm
Cutting depth (90º)	114.3 mm
Sound pressure level	107 dB
Saw blade included	Yes
Diamond disc	-
Cutting capacity 0°	100 x 100 mm
Cutting capacity 45° miter	100 x 85 mm
Power source	AC

Weight and Dimensions

Depth	514.35 mm
Weight	19300 g
