Makita UC4051A User Manual

8
DESIGNATION OF PARTS
(Nut model: the sprocket cover is tightened by nuts.)
For Model UC3050A, UC3550A, UC4050A, UC4550A
1
2
3
4
5
6
9
10
8
014372
(Lever model: the sprocket cover is tightened by lever.)
For Model UC3051A, UC3551A, UC4051A, UC4551A
1
2
3
4
5
6
9
10
8
7
014373

Makita UC4051A Specifications

General

Power source	AC
AC input voltage	240 V
Idle speed	- RPM
Chain gauge	1.27 mm
Chain pitch	3/8 \
Chain speed	14.5 m/s
Blade length	- mm
Product color	Black, Blue
Automatic oiling	Yes
Chain bar length	400 mm
Oil tank capacity	0.2 L
Vibration emission	1.5 m/s²
Motor power	1800 W

Weight and Dimensions

Width	200 mm
Height	220 mm
Length	505 mm
Weight	5400 g
