7 ENGLISH
PARTS DESCRIPTION
XNU02
XNU01
6
7
8
9
3
4
5
1
14
4
5
6
7
9
1
2
10
11
13 12
1 Head 2 Front grip 3 Hanger 4 Lever
5 Batterycartridge 6 Rear grip 7 Switch trigger 8 Slide sleeve
9 Shear blades 10 Speed indicator 11 Power lamp 12 Reverse button
13 Main power button 14 Handle - - - -
