8 ENGLISH
PARTS DESCRIPTION
10 11
12
14
15
3
2
4
5
879
13
6
1
16
17
18
20
21
22
19
1 Slide pole 2 Stopper pin
(for carriage sliding)
3 Vertical vise 4 Releasing button
(for right side bevel angle)
5 Holder 6 Turn base 7 Pointer (for miter angle) 8 Miter angle scale
9 Kerf board 10 Blade case 11 Adjusting screw
(for laser line)
12 Range adjustment screw
(for laser line)
13 Blade guard 14 Knob (for bevel angle) 15 Hex wrench 16 Adjusting screw
(for lower limit position)
17 Adjusting bolt (for maxi-
mum cutting capacity)
18 Stopper arm 19 Battery cartridge 20 Lock lever (for turn base)
21 Releasing lever
(for turn base)
22 Grip (for turn base) - - - -
