2 CX Start up
__________________________________________________
Before starting up the MALÅ CX GPR system the following connections
must be made:
- The CX to the antenna, using the antenna cable. The antenna cable
should always be connected before the CX unit is powered on.
- The CX to the battery or other power source, using the battery cable.
See Chapter 11.
- The encoder wheel to the antenna.
When all connections have been made, the CX can be turned on. Pressing
the On/Off button at top right-hand corner activates the system. More
information on the High Frequency Antennas can be found in Chapter 12.
Note! The antennas should be ON for a while before measurement, to
warm-up. An appropriate time is approximately 10 minutes.
Once active, the CX is operated using a dual function turn-push button
(bottom right on the monitor) to control the settings. By turning the button
right or left, a selection from a specific menu can be highlighted. By
pushing the button, the selection is activated.
