5 Object-Mapper Project
__________________________________________________
An Object-Mapper Project is a tool to easily handle and interpret radar
profiles acquired with the MALÅ CX system, where a number of radar
profiles are measured parallel starting from a common baseline. See the
example below.
Applications can be for instance; mapping pipes, conduits or other larger
linear structures, over larger areas.
Once an Object-Mapper Project is created within the MALÅ CX, it can be
directly opened in Object Mapper, a Windows based interpretation software
for quick mapping of underground features. For further information, see the
Object Mapper Operating Manual.
When the Measurement settings are made, (see Chapter 2 above) press
and choose the appropriate settings for the Object-Mapper
Project:
