Malabar 795 - Jack Assembly Parts Breakdown; Main Jack Assembly

FIGURE 1A
CYLINDER ASSEMBLY
RESERVOIR (NO R/C KIT)
TRIPOD HEAD PIN
RETAINING RING
VALVE BLOCK ASSEMBLY
SWIVEL CASTER
RESERVOIR STRAP
TOW HANDLE
SPACER
HHCS, 1/2-13 x 1 1/2 LG
HHCS, 1/2-13 x 1 3/4 LG
HHCS, 3/4-10 x 4" LG
FLAT WASHER, 1/2
SPLIT LOCKWASHER, 1/2
SPLIT LOCKWASHER, 3/4
HEX NUT, 1/2-13
HEX NUT, 3/4-10
ELBOW, 3/8 T x 3/8 SAE
TUBE, 3/8 O.D. x .065 WALL
19 A/R 732-010
20 2 55998
21 1 75940
22 1 717-008
23 1 717-003
24 1 78915
25 1 MS28778-6
26 1 79543
27 1 717-001
28 12 325-001
29 1 881802-1
30 2 881802-2
31 6 79507
32 1 79574
33 1 881818
34 1 78975
35 1 78990
36 1 79653
37 1 73148
NO. QTY PART NO. DESCRIPTION
MODEL 795 JACK ASSEMBLY
- 13 -
1 1 79599
2 1 79391
3 3 79612
4 6 55923-200
5 1 56010-1
6 3 79536A
7 1 79557
8 1 79535
9 1 78985
10 4 321-014
11 12 321-006
12 1 321-010
13 14 362-005
14 16 363-004
15 1 363-006
16 14 351-003
17 1 351-004
18 1 722-018
19 A/R 732-010
NO. QTY PART NO. DESCRIPTION
27
9
10
13
14
19
18
25 ♦
TUBE, 3/8 O.D. x .065 WALL
STICKER, MALABER
STICKER, TOWING
PLUG, USED w/ NO AIR PUMP
PLUG, USED w/ NO AIR PUMP
AIR PUMP KIT
O-RING (PART OF ITEM 18)
ADJUSTABLE FOOT KIT
PLUG, USED w / NO GAUGE
FSHCS, 1/2-13 x 1 3/4 LG
SWIVEL CASTER
SWIVEL CASTER w/ LOCK
BRACE, USED w/ HYD. CAST.
ADJ. FOOT KIT w/ HYD. CAST.
SHOCK ABSORBER KIT
RESERVOIR (R/C KIT)
REMOTE CONTROL KIT
RESERVOIR (ELEC. MOTOR)
ELEC. MOTOR / PUMP KIT
11
13
14
16
6
7
24
10
14
16
23
5
36
2
34
22
20
55998
20
37
35
1
26
28
29
30
8
6 (REF)
12
15
17
♦ PART OF REPAIR PARTS KIT
3
4
21
31
33
DRAIN
32
