Malabar 795 - Load Gauge Kit Parts Breakdown; Load Gauge Kit Diagram

79546 LOAD GAUGE KIT
NO. QTY PART NO. DESCRIPTION
8 1 714-001
9 1 711-003
10 1 424-001
11 1 722-021
12 1 721-011
13 A/R 732-003
14 1 MS28778-4
- 21 -
FIGURE 7
LOAD GAUGE
SHCS, 10-32 x 3 1/2 LG
SPLIT LOCKWASHER, # 10
HEX NUT, 10-32
SPACER
TEE, 1/4 FPT
PLUG, 1/4 MPT
NO. QTY PART NO. DESCRIPTION
1 1 79368
2 3 323-072
3 3 363-009
4 3 351-008
5 3 876025
6 1 713-002
7 1 717-006
11
10
13
REDUCER, 1/2 FPT x 1/4 MPT
NIPPLE, 1/4 MPT
SHUTOFF VALVE
ELBOW, 1/4 T x 1/4 MPT
CONNECTOR, 1/4 T x 1/4 SAE
TUBE, 1/4 O.D. x .035 WALL
O-RING (PART OF ITEM 12)
12
14 ♦
8
9
7
6
1
3
4
5
2
♦ PART OF REPAIR PARTS KIT
