Malabar 795 - Hydraulic Caster Assembly Parts Breakdown; Hydraulic Caster Assembly Diagram

5
FIGURE 10
881800 HYDRAULIC CASTER ASSEMBLY
NO. QTY PART NO. DESCRIPTION
12 1 372-009
13 1 373-005
14 1 483-006
15 1 712-060
16 2 717-005
17 1 717-006
18 2 722-018
19 A/R 732-024
20 2 MS28778-6
21 1 881817
- 24 -
PLUNGER
CYLINDER
CAP
RETAINING SCREW
RESERVOIR & BASE
VALVE BLOCK & HAND PUMP
CASTER MOUNTING PLATE
O-RING
O-RING
O-RING
BACK-UP RING
NO. QTY PART NO. DESCRIPTION
1 1 881803
2 1 881804
3 1 881805
4 1 881806
5 1 881807
6 1 881808
7 1 881809
8 2 55925-040
9 1 55925-045
10 1 55925-330
11 1 55929-330
16
7
DRAIN
COTTER PIN, 3/32 x 1/2 LG
FLAT HEAD PIN, 3/8 DIA
BREATHER, 1/8 MPT
ELBOW, 1/8 MPT x 1/8 FPT
PLUG, 1/8 MPT
PLUG, 1/4 MPT
ELBOW, 3/8 TUBE x 3/8 SAE
TUBE, 3/8 OD x .035 WALL
O-RING (PART OF ITEM 18)
SETSCREW ORIFICE
2
8 ✚
12 ✚
13 ✚
4 ✳
18
20 ✚
6
16
18
✚ 20
17
✳ 21
19
3
1
✚ 10
9 ✚
11 ✚
8 ✚
✚ PART OF HYDRAULIC CASTER
REPAIR PARTS KIT
✳ APPLY LOCTITE NO. 242 ON
THREADS
14
15
