Malabar 795 - Adjustable Foot Kit with Hydraulic Caster Parts Breakdown; Kit Diagram and Components

79574 ADJUSTABLE FOOT KIT WITH HYDRAULIC CASTER
10 3 363-005
11 3 79343
12 3 79346
13 18 325-001
14 3 79336
15 3 75941
16 3 881800
17 12 321-005
18 12 363-004
FIGURE 9
NO. QTY PART NO. DESCRIPTION
TRIPOD LEG
TRIPOD LEG w/ TOW BRKT
TRIPOD LEG w/ HANDLE HLDR
LONG SPRING PIN
RETAINING RING
SPRING
SHORT SPRING PIN
FOOT SCREW
GUIDE SCREW
- 23 -
NO. QTY PART NO. DESCRIPTION
1 1 79572
2 1 79577
3 1 79579
4 3 76376
5 12 55923-75
6 3 79344
7 3 79348
8 3 79339
9 3 76377
14
SPLIT LOCKWASHER, 5/8
FOOT SCREW LOCKNUT
RETAINING RING
FSHCS, 1/2-13 x 1 1/2 LG
FOOTPAD
STICKER, FOOTPADS
HYDRAULIC CASTER ASS'Y
HHCS, 1/2-13 x 2" LG
SPLIT LOCKWASHER, 1/2
13
12
17
18
DRAIN
16
1
2
3
9
10
7
5
8
11
4
5
6
15
